پلاگین ویژوال آرک 3.1 (Visual ARQ) برای راینو 8

Link objects to levels

Objects can be attached to levels. When editing a level elevation, all objects contained in that level update their position or height.

Buildings with boundary

Buildings can have a boundary, which allows you to hide, show, and isolate them. An Environment entity has been added to show or hide the geometry beyond the building boundaries.

Isolate levels

Since buildings have a boundary, levels can be hidden and isolated individually.

Sub-levels

Option to add new sub-levels between levels, with their own construction plane.

Save level states

Save level and building configurations that can be restored at any time to selected viewports.

Synchronize Level states in viewports

Copy and keep the buildings and levels visibility status from one viewport to all viewports while working.

Toggle’s level elevation

Level references and elevations can be displayed in relation to the building’s elevation or the Document’s Elevation.

Create multiple levels

Option to create multiple levels (or sub-levels) at once, with a specific pattern for names, heights between levels, and other default settings.

Edit level height

The elevation of a level can be changed by editing the level’s height.

Real-time ceiling views

Show the reflected parallel view of a specific level in any viewport. (Only in Rhino 8)

2D ceiling plans

Insert 2D ceiling plans in the model space. These plans are linked to the 3D model and can update at any time.

Quantity take-offs in a dynamic report panel

Show quantity take-off reports in real-time of VisualARQ objects and Rhino geometry in a Table Report panel.

Table filters

Filter objects displayed in the table report panel by style, building, level, or layer.

Bi-directional tables

The table report shows the information on objects in the model. However, some object properties can be edited directly by clicking on the corresponding cell in the table.

Table Totals

Show the sum, count, or average of object information in table panels for the desired property field.

Identify elements in the model

Select the elements in the table panel and see them highlighted in the model for easy identification. You can also zoom in on the selection.

New export options

Control whether to export values with units or not and the possibility to change dots by commas when exporting tables to Excel.

Add or remove objects to/from tables

Tables can be dynamic, so new objects will be automatically reported or can display a manual selection of objects, with the option to include or remove items from the list.

New guide entity

Guides help you maintain accuracy and precision in your project and therefore promote consistency throughout the design process. They act as reference points and aid in aligning different elements of the design.

Link VisualARQ and Rhino objects to guides

VisualARQ objects and Rhino geometry get linked to guides, so they move or stretch when guides change position. The guide styles can determine which object types are linked to guides, and other display features.

Guides grid and guides from curves

Insert guides arranged in a rectangular grid, with automatic naming control of their labels.

Guides can be also created from any planar curve.

Range and control points

Guides have control points and top and bottom extension arrows that let you change their vertical range and label position.

Guides display

Guides are displayed on the construction plane of the current floor in the Top and Perspective views and as vertical reference lines in elevation views. They can also be displayed on all levels simultaneously.

Walls from Grasshopper styles

Create new wall styles from Grasshopper definitions, with unlimited parametric design possibilities. Openings can be inserted into these walls as well.

Wall joints from Grasshopper styles

Walls created from Grasshopper definitions join at their corners, and there is the option to break this join.

Curtain walls from surfaces

Select any planar Rhino surface and turn it into a Curtain wall

Curtain walls from Grasshopper styles

Create new curtain wall styles from Grasshopper definitions, with unlimited parametric design possibilities.

Custom profiles for the Frame and the Mullion components

Adjust division count in extended curtain walls

When the cell division type is set to a “fixed number of cells“, the cell division count can be preserved when extending curtain walls.

Insert doors and windows in slabs and roofs

Doors and windows can define which object type supports as a host, and therefore they can be inserted in slabs and roofs.

Slanted openings

Doors and windows can rotate freely in the 3D model space. When they detect a host, they are inserted and oriented automatically accordingly.

Handle component

Add handles to your window and door styles. Choose between Lever, Knob, or Embedded types, with different parameters for their location, or the Escutcheon shape.

Leaf width by percentage or fixed dimension

Door and window styles that combine different leaves, can get their widths determined by equitative values, a fixed dimension, or a percentage.
